Welded Wire Mesh for Reinforced Concrete Slabs

Gambar besar : Welded Wire Mesh for Reinforced Concrete Slabs

Detail produk:

Tempat asal:	Cina
Nama merek:	QIJIE
Sertifikasi:	SGS, ISO
Nomor model:	QJ-WMP-01

Syarat-syarat pembayaran & pengiriman:

Kuantitas min Order:	1000 Meter Persegi
Harga:	USD 0.5-5/M2
Kemasan rincian:	palet
Waktu pengiriman:	10-15 hari kerja
Syarat-syarat pembayaran:	30%tt
Menyediakan kemampuan:	1000 meter persegi per hari

Kontak

Detil Deskripsi produk

Bentuk lubang:	Persegi, persegi panjang, lubang panjang	Pengukur kawat:	0.5mm-14mm,2.0-4.0mm,BWG#12--#26,0.3-2.5mm,0.3mm-8.0mm
Aplikasi:	Konstruksi Wire Mesh, Pagar Mesh, gedung, jembatan, Pagar taman	Jenis:	Welded Mesh, Wire Mesh Listrik, Panel atau gulungan
Bukaan:	1/2",1/4"-6",1" x 2" dll	Perawatan Permukaan:	Hot Dipped Galvanized, dilapisi pvc, dilapisi galvanis / pvc, dilapisi bubuk
Lebar:	0,5-2m,0,5-1,8m,300mm-2500mm,0,5m hingga 2,2m,1,2m	Panjang:	30m, 50m, 10m, 5m, 25m
Penggunaan:	Perlindungan, bangunan, konstruksi	sedang mengemas:	Palet, dalam jumlah besar
Nama Produk:	wire mesh dilas, Wire Mesh Dilas Galvanis / Dilapisi PVC	Warna:	Perak, Hijau, Abu-abu, dll
Nama:	dilas wire mesh,Stone Cage Net,pvc dilapisi beton bertulang dilas wire mesh untuk dijual	ukuran lubang:	5/8'' sebagai permintaan pelanggan
Diameter Kawat:	1.0mm ~ 4.50mm	Ukuran jaring:	50x100mm
E-mail:	devin@industrialmetalmesh.com	ada apa:	+8615369013183
Menyoroti:	welded wire mesh for concrete slabs , reinforced concrete wire mesh , welded mesh with concrete reinforcement

Welded Wire Mesh for Reinforced Concrete Slabs

Welded wire mesh is also known as external wall insulation wire mesh, galvanized wire mesh, galvanized welded wire mesh, steel wire mesh, row welded wire mesh, butt welded wire mesh, construction mesh, exterior wall insulation mesh, decorative mesh, wire mesh, square mesh, screen mesh, anti-cracking network.
It is made of high-quality low-carbon steel wire row welding, and then cold plating (electroplating), hot plating, PVC plastic coating and other surface passivation, plasticization treatment.
It can achieve smooth mesh surface, uniform mesh, firm solder joints, good local machining performance, stability, good weather resistance, and good corrosion resistance.

The specifications for welded wire mesh can vary based on the intended use, but common aspects include:

1,Wire Diameter: Ranges from 1.0 mm to 6.0 mm, affecting the mesh's strength and flexibility.

2,Mesh Opening Size: Typically ranges from 12 mm x 12 mm to 50 mm x 50 mm, allowing for different levels of airflow and visibility.

3,Sheet Size: Common dimensions include 1m x 2m, 2m x 4m, or custom sizes based on project requirements.

4,Material: Often made from stainless steel, galvanized steel, or PVC-coated wire for enhanced corrosion resistance. 5,Surface Treatment: Options include hot-dip galvanizing, electro-galvanizing, or plastic coating for added durability.

1. Welded wire mesh panel Material:

>low carbon steel wireQ195
>galvanized iron wire
>pvc coated iron wire
>stainless steel wire

2. Welded wire mesh panel type

> Galvanized Welded Mesh Panels
> Welded Stainless Steel Wire Mesh Panels
>Hot-dip Zinc Plating Welded Mesh Panels
>PVC coated Welded Mesh Panels
>Galvanized welded wire mesh rolls
>Pvc coated welded wire mesh rolls

3. Welded wire mesh panel Characteristics:

> High intensity anti-high temperature.
> Better strength and strong integration
> Flat & even surface and strong structure
> Anti-rust property
>Not easy to loosen even be cut into parts or exerted force on the parts

> A long service life and the service life can reach to several decades

4.Welded wire mesh panel Processing

a>Hot dipped galvanizing before welding
b>Hot dipped galvanizing after welding
c>Welding with iron wire
d>Electric galvanizing after welding
e>PVC coated welded wire mesh panel

Opening		Wire Diameter	Width 0.4-2m Length 5-50m	electric galvanized before welded, electric galvanized after welded, hot-dipped galvanized before welded, hot-dipped galvanized after welded, PVC coated, Stainless steel wire
Inch	Metric Unit	Wire Diameter
1/4"x1/4"	6.4mmx6.4mm	BWG24-22
3/8"x3/8"	10.6mmx10.6mm	BWG22-19
1/2"x1/2"	12.7mmx12.7mm	BWG23-16
5/8"x5/8"	16mmx16mm	BWG21-18
3/4"x3/4"	19.1mmx19.1mm	BWG21-16
1"x1/2"	25.4mmx25.4mm	BWG21-16
1-1/2"x1 1/2"	38mmx38mm	BWG19-14
1"x2"	25.4mmx12.7mm	BWG16-14
2"x2"	50.8mmx50.8mm	BWG15-12
2"x4"	101.6mmx101.6mm	BWG15-12
4"x4"	101.6mmx152.4mm	BWG15-12
4"x6"	101.6mmx152.4mm	BWG15-12
6"x6"	152.4mmx152.4mm	BWG15-12
6"x8"	15.4mmx203.2mm	BWG14-12
Note:Special specification can be made according to customers requires

Application
Welded wire mesh is widely used in industry, agriculture, construction, transportation, mining and other industries.
Such as machine guards, animal fences, flower and wood fences, window fences, passage fences, poultry cages, egg baskets and home office food baskets, paper baskets and decorative use.
It is mainly used for general building exterior walls, pouring concrete, high-rise residences, etc., and plays an important structural role in the thermal insulation system. During construction, the hot-dip galvanized welded mesh frame polystyrene board is placed on the inner side of the exterior wall outer formwork to be poured. , the external thermal insulation board and the wall survive at one time, and the thermal insulation board and the wall are integrated into one after the mold is removed.

Welded Wire Mesh Panel is made of superior quality welded mesh, with flat even surface, firm structure, be used extensively in building, food, agriculture and so on.
