High Ribbed Formwork 0.35mm Galvanised Metal Rib Lath for Construction

Gambar besar : High Ribbed Formwork 0.35mm Galvanised Metal Rib Lath for Construction

Detail produk:

Tempat asal:	Hebei, Tiongkok
Nama merek:	XMESH
Sertifikasi:	SGS
Nomor model:	1/8" 0,35mm

Syarat-syarat pembayaran & pengiriman:

Kuantitas min Order:	200 buah
Kemasan rincian:	palet
Waktu pengiriman:	15-25 hari
Syarat-syarat pembayaran:	TT, LC,
Menyediakan kemampuan:	1000/pcs

Kontak

Detil Deskripsi produk

Bahan:	Lembaran Baja Galvanis	Ukuran:	610x2440mm
Tinggi tulang rusuk:	1/8"	Ketebalan:	0,35mm
Aplikasi:	Melindungi Mesh, Layar	Jenis:	Expanded Mesh, Flattened dan Standard, tipe Raised
Teknik:	Berlubang, Tenun	Gaya menenun:	logam yang diperluas
Perawatan Permukaan:	Hot Dip Galvanized, Powder Coated, Galvanized, Powder Coating	Nama Produk:	Jaring Logam yang Diperluas, Logam Aluminium yang Diperluas
Fitur:	Ketahanan Korosi, Tahan Lama, Cantik, dipernis, Mudah Dirakit	Penggunaan:	Filter Cair, layar, Konstruksi
Bentuk lubang:	Lubang berlian	Panjang:	30m
Lebar:	0,5-2m	sedang mengemas:	kotak kayu, film plastik, palet
Jalan Pendek:	2-40mm	Mencicipi:	Bebas
E-mail:	devin@industrialmetalmesh.com	ada apa:	+8615369013183
Menyoroti:	galvanized metal rib lath , high ribbed formwork mesh , 0.35mm expanded metal lath

High Ribbed Formwork 0.35mm Galvanised Metal Rib Lath for Construction

High Ribbed formwork is manufactured from hot-dipped galvanized steel sheets. Because its meshes and U patterns, it has better anti-stress capability and forming flexibility than normal metal lath. This product has excellent engineering quality, construction security and widely used in building construction to form retaining walls, columns, stop ends, construction joints and used to support slab flooring.

Rib Metal Lath

High Bond Strength: The deep ribs allow the concrete or plaster to adhere more effectively, increasing the overall structural integrity. Flexibility

Rib Mesh can be easily shaped and adapted to complex forms, making it ideal for irregular or curved surfaces. Lightweight: Despite its strength,

Rib Mesh is relatively lightweight, reducing the load on structural elements and simplifying handling on-site. Efficient Installation:

The design reduces the need for extensive support structures during installation, cutting down on labor and material costs.

Rib lath is popularly known as Expanded Rib Lath, due to its process of expanding of metal sheet. Galvanized steel ribbed lathe
offers ideal building material for plastering base, structural form work and fireproofing construction.
Ribbed Lath made of galvanized steel has anti-corrosion properties and allows for smooth application of coatings such as plaster.
Ribbed Lath offers an adaptable, low cost and efficient solutions for a wide range of construction requirements.

3. Specification

Rib Lathes, 5 Rib, 7 Rib and 9 Rib Design

Rib Type	Thickness(mm)	Rib Distance(mm)	Weight (KG)	Width X length(mm)
7 Rib	0.30	100	1.79	610 X 2440
	0.35	100	2.09	610 X 2440
	0.40	100	2.38	610 X 2440
	0.45	100	2.68	610 X 2440
	0.5	100	2.98	610 X 2440
5 Rib	0.30	150	1.31	610 X 2440
	0.35	150	1.53	610 X 2440
	0.40	150	1.75	610 X 2440
	0.45	150	1.96	610 X 2440
	0.5	150	2.17	610 X 2440
9 Rib	0.30	75	1.89	610 X 2440
	0.35	75	2.28	610 X 2440
	0.40	75	2.53	610 X 2440
	0.45	75	2.84	610 X 2440
	0.5	75	3.15	610 X 2440
Other specifications can be customized according to customer requirements

Normal Weight Specification
The expanded metal lath is commonly available in following weights:
1.75 lbs per square yard;
2.5 lbs per square yard;
3.4 lbs pounds per square yard.

High Ribbed Formwork 0.35mm Galvanised Metal Rib Lath for Construction 0

High Ribbed Formwork 0.35mm Galvanised Metal Rib Lath for Construction 1
