Detail produk:
Syarat-syarat pembayaran & pengiriman:
|
| Jenis: | kumparan kawat berduri | Model berduri: | Bto-22, Cbt-65 |
|---|---|---|---|
| Spesifikasi: | 7-16m | Diameter luar kumparan: | 960mm |
| karakter: | Mudah Dipasang, Anti Korosi, Anti Karat, Dll | Penggunaan: | Sangat Bagus untuk Perumahan, Industri & Komersial |
| Panjangnya: | Umum Adalah 1.0m-50m atau sebagai Permintaan Anda. | Ukuran Jaring: | 40x40mm, 50x50mm, 60x60mm, 70x70mm, dll. |
| Pengobatan permukaan: | Galvanis | Fitur: | Mudah Dirakit, Ramah Lingkungan, Anti Tikus, Rot |
| Cahaya Tinggi: | Kawat berduri concertina 960mm,kawat berduri concertina chain link,pagar kawat bto-22 concertina |
||
Pagar Rantai Tautan Galvanis |
|||||
jala (mm) |
pengukur kawat (SWG) | Diameter Kawat (mm) | Berat Kg/m2 | Diameter kumparan (cm) |
|
| volume alami | Lipat volume | ||||
| 200 × 200 | 8 | 4.06 | 1 | 60 | 35 |
| 150 × 150 | 10 | 3.25 | 0.9 | 55 | 32 |
| 100 × 100 | 9 | 3.66 | 1.7 | 55 | 35 |
| 80×80 | 10 | 3.25 | 1.68 | 57 | 38 |
| 60 × 60 | 12 | 2.64 | 1.5 | 52 | 34 |
| 50 × 50 | 12 | 2.64 | 1.83 | 49 | 33 |
| 40 × 40 | 10 | 3.25 | 3.56 | 46 | 32 |
| 30 × 30 | 12 | 2.64 | 3.25 | 42 | 34 |
| 20 × 20 | 19 | 1.02 | 0,7 | 25 | 34 |
Pagar Rantai Tautan Dilapisi PVC |
|||||
| jala (mm) | pengukur kawat (SWG) | Diameter Kawat (mm) | Berat Kg/m2 | Diameter kumparan (cm) |
|
| volume alami | Lipat volume | ||||
| 80×80 | 8 | 3.0/4.06 | 1.72 | 65 | 40 |
| 60 × 60 | 9 | 2.6/3.66 | 1.75 | 59 | 38 |
| 55 × 55 | 10 | 2.2/3.25 | 1.38 | 54 | 35 |
| 50 × 50 | 10 | 2.2/3.25 | 1.67 | 49 | 35 |
| 45 × 45 | 8 | 3.0/4.0 | 3.2 | 50 | 35 |
| 40 × 40 | 10 | 2.2/3.25 | 2 | 45 | 34 |
| 35 × 35 | 12 | 2.0/2.64 | 1.9 | 40 | 30 |
